LiteCore Marine Wall Panel – A15
The LiteCore A15 marine wall panel is a certified lightweight fire-resistant solution developed for use in ships, offshore units, and accommodation areas at sea.
Built with a durable, non-combustible calcium silicate core, the A15 panel meets IMO FTP Code requirements for A15 fire protection.
Thanks to its low density of approximately 300 kg/m³, the panel combines minimal weight with high structural stability, ideal for modern vessel construction where both fire safety and low weight are key.
LiteCore A15 panels can be supplied in a wide selection of decorative and technical finishes, such as HPL laminate, stainless steel, galvanized steel, or other custom surfaces to match project specifications.
Extremely lightweight • Easy to install • IMO-certified • Resistant to moisture
Technical properties
| Fireclass | A15 |
| Approval | IMO FTP 2010 – Wheelmark – DNV |
| Thickness core (mm) | 25 mm |
| Width x Length (mm) | 590×2400 mm |
| Dry Density core (kg/m3) | 250 kg/m3 |
| Dry Density core (kg/m2) | 6,25 kg/m2 |
| Material | Calcium Silicate |
| Asembly method | Tongue and groove |
Download
Product Information | Installation Guide | Surfaces | Datasheet | Certificate | 3D CAD
Related Products
A0 | A15 | A30 | A60 |B0 | B15
DID YOU KNOW?
Did you know that “A0” division is able to maintain its integrity for a period of 60 minutes?
However because it is “0” rated, the cold face temperature can rise without limit.
An “A60” division is able to maintain both its integrity and insulation criteria for a period of 60 minutes.
