LiteCore Marine Wall Panel – A30
To meet A30 fire protection requirements using LiteCore marine wall panels, we refer to the LiteCore A60 wall panel.
The A60 panel is a lightweight, fire-resistant solution designed for marine and offshore environments.
Developed for use in bulkheads, accommodation areas, and shipbuilding applications, the A60 panel ensures reliable fire performance while maintaining a low overall weight.
Constructed with a non-combustible calcium silicate core, the LiteCore A60 panel meets IMO FTP Code requirements for A60-class fire protection.
Its low density of 250 kg/m³ provides an excellent strength-to-weight ratio, making it ideal for modern vessels where weight efficiency and safety are essential.
LiteCore A60 panels are available with a wide range of surface finishes, from durable laminates to galvanized or stainless steel, allowing seamless integration into both functional and aesthetic marine designs.
Certified for A class fire protection • Fast installation • Multiple surfaces available
Technical properties
| Fireclass | A60 |
| Approval | IMO FTP 2010 – Wheelmark – DNV |
| Thickness core (mm) | 52 mm |
| Width x Length (mm) | 580×2400 mm |
| Dry Density core (kg/m3) | 300 kg/m3 |
| Dry Density core (kg/m2) | 15,6 kg/m2 |
| Material | Calcium Silicate |
| Asembly method | Tongue and groove |
Download
Product Information | Installation Guide | Surfaces | Datasheet | Certificate | 3D CAD
Related Products
A0 | A15 | A30 | A60 |B0 | B15
DID YOU KNOW?
Did you know that “A0” division is able to maintain its integrity for a period of 60 minutes?
However because it is “0” rated, the cold face temperature can rise without limit.
An “A60” division is able to maintain both its integrity and insulation criteria for a period of 60 minutes.
